I do have a small batch in production right now which should be delivered some time next week if anybody wants one.Įxcellent, excellent work brutha.
#2100 IN 1 JAMMA BOARD KICK CONNECTOR DOWNLOAD#
Here is a link to OshPark where you can download the gerbers if you want to have this manufactured. I will be using this with my NNC through JAMMAfier. This is just the first step to get it running on my personal setup. I hope to evolve this into an active design that amplifies the audio and video so it can be used on 15khz only monitors and Mono cabinets. This first version is fully passive, It doesn't amplify the video or audio meaning that it will only work properly with a Tri-Sync monitor and a stereo cabinet with a dedicated audio amp. Kicks are output to a CPS2 style kick harness connector. This board takes RGB SCART input and passes it to the JAMMA edge, audio is output through 2 RCAs which can be connected to the cabinet's amplifier, and controls are meant to be handled by a pair of Brook Retro Boards connected via 20 Pin Harness. 31khz sources will only work with 31khz capable monitors. This adapter works for MAME in both 15khz and 31khz modes and VGA capable consoles like the Dreamcast and Xbox 360. The VGA hat has a sync combiner that can be toggled on or off depending on the needs of the VGA source. VGA Input Hat: This accessory will connect to the EXT_IN port of the man Console JAMMAizer PCB and provide VGA and 3.5mm audio input.Rapid fire modes can be toggled between different speeds and can be toggled between V-Sync locked timing and asynchronous timing depending on your needs.
#2100 IN 1 JAMMA BOARD KICK CONNECTOR FULL#
Allows full remapping and rapid fire programming of buttons 1-6 for player 1 and 2. Button Remapping and Rapid Fire IC: Designed by "RGB" creator of the HAS supergun and RECO PCB.Hard Gold plated, beveled and chamfered JAMMA edge.
